Rapid roll dooors  is the necessary equipment for efficient operation of industrial factory because it has many functions such as quick opening and closing, temperature insulation and heat preservation, dustproof and insect-proof, soundproof protection and so on. It has always been SEPPES's belief to develop fast doors that make customers more satisfied. SEPPES can provide a variety of customized solutions to make the use of rapid doors more intelligent and humanized. In this article, we will explain in detail the customization services that we can provide.

Color and thickness of pvc high speed door curtain

The regular colors of the door curtains are: yellow, blue, red, white and grey, in addition you can customize them according to the RAL color card. Most of the companies we have worked with will choose yellow, blue and red, which are more vibrant, bright and energetic colors for door curtains. Of course to make your factory more aesthetically pleasing and the overall colors more coordinated, you can customize the colors to fit your own factory.

The regular thickness of the door curtain is 0.8mm, if your actual use of the scene needs the door curtain anti-static or have higher requirements for the wind resistance of the door curtain, can be customized 1.2mm, 2.0mm, 2.5mm.

Opening speed of high speed door

The standard speed of SEPPES fast door is 0.8-1.2m/s, if you want to be faster, you just need to change the configuration, it can reach 1.2-2.0m/s. Fast partition, keep dust-free and clean, constant temperature and humidity, and help your enterprise to save energy, reduce emission, and reduce the operation expense.

Motor position of high speed roll up doors

The mounting position of motor is not fixed, left side, right side, front, built-in are all available. Because the actual installation space of each enterprise is different, we will customize a unique installation plan for you according to the actual use scenario.

Safety protection devices for high speed shutter door

The standard protection for SEPPES fast doors is infrared safety photoelectric protection, installed at the bottom of the door frame, when people or goods pass underneath to enter the induction area, the door will rise quickly to prevent safety hazards.

Optional safety bottom edge airbags and safety light curtains are also available. Safety bottom edge, adding airbags to the U-shaped bottom pockets of the door curtains, when the door is falling, if someone or object passes by, the airbag will be squeezed by deformation, the signal will be sent to the control box, the door will automatically rise to ensure the safety of staff and products. Safety light curtain, more than photoelectric add a few infrared sensing photoelectric, sensing area increased, safety is also improved.

Various opening methods for rapid roll doors

The standard opening method of the rapid door is double-sided manual button, can be optional radar, bluetooth, geomagnetic induction, wireless switch, remote control, card access control, pull rope and so on.

You can set to adjust the sensing range of the radar, when people or objects enter into the range, the radar will automatically detect and open the door, which greatly improves the operational efficiency of the enterprise. Geomagnetic induction is mainly applicable to the entry and exit of forklift trucks, working through the induction coil buried under the ground. When the forklift approaches, the magnetic field around the coil changes, triggering the induction signal, which in turn controls the door opening.

Enterprise customers can choose and match as needed to realize the fully automatic switching operation of the product, as well as with the equipment signal linkage or remote control, to help create an unmanned intelligent factory.

Blackout devices for fast action doors

It can be equipped with a manual chain device or a reserve power supply to ensure the normal operation of the plant in case of power failure. The reserve power supply can be turned on about 20 times during a power outage, and you only need to charge the reserve power supply during normal times.

Track material of rapid roll doors

The material of SEPPES rapid door track is 2.0mm thick cold rolled steel plate with baking paint. It can be customized with 304 stainless steel or aluminum alloy. Stainless steel has better corrosion resistance and is easier to clean, greatly improving the service life of the product.

In today's fast-developing industrial field, more and more enterprises begin to pay attention to the production environment, operational efficiency and energy consumption of the factory. As an efficient, energy-saving, safe entrance and exit door type, rapid roll doors are widely used in various electronic, pharmaceutical, warehousing, food, machinery and other industries.
